Beontag – Viking Micro+
The Beontag Viking Micro+ is a compact, industrial-grade Bluetooth® Low Energy (BLE) tag engineered for reliable asset identification and traceability in demanding environments. With a non-replaceable coin cell battery providing up to 8 years of typical use, it supports Eddystone™ and iBeacon® protocols for seamless integration into existing BLE ecosystems. Its rugged construction, IP68 water resistance, and chemical durability make it ideal for manufacturing, logistics, automotive, and supply chain operations where space is limited and resilience is essential.
Specification
Wireless & Protocols:
-
Bluetooth® Low Energy tag, battery powered
-
Bluetooth® 5.3
-
Supported protocols: Eddystone™ (UID, URL, TLM), iBeacon®
-
Frequency: 2.4 GHz ISM (2402–2480 MHz)
-
Max TX power: +4 dBm
-
Read range: up to 70 m at 0 dBm (environment dependent)
-
SOC: InPlay IN100
-
Configured at ordering (customer-specific parameters)
Sensors:
-
Built-in temperature sensor (internal housing)
-
Hall switch
-
Battery voltage monitoring
Battery & Power:
-
Non-replaceable coin cell:
-
CR2032: 220 mAh, up to 6 years lifetime
-
CR2050: 380 mAh, up to 8 years lifetime
-
Mechanical:
-
Housing: High-quality PC+ASA with polyurethane coating
-
Dimensions:
-
CR2032: 36 × 26 × 6 mm, 10 g
-
CR2050: 36 × 26 × 8 mm, 14 g
-
-
Color: Dark grey (Pantone 433U)
-
Mounting: High-performance acrylic adhesive or cable tie (max width 4 mm)
Environmental Resistance:
-
Operating temperature: –20 °C to +60 °C
-
IP68 water resistance (1 m submersion for 5 hours)
-
ESD: ±8 kV (air), ±4 kV (contact)
-
Chemical resistance: Motor oil, salt water, sulfuric acid, NaOH (avoid acetone)
Packaging:
-
CR2032: 30 pcs per box (30 × 40 × 250 mm)
Order Codes:
-
3005640 / 3005641 – CR2032 (Eddystone/iBeacon)
-
3005642 / 3005643 – CR2050 (Eddystone/iBeacon)
Benefits
Small form factor with long-range BLE communication for space-constrained applications without sacrificing performance.
Non-replaceable coin cell powers the device for up to 8 years, reducing maintenance in large-scale deployments.
IP68-rated, chemically resistant housing and flexible mounting options ensure reliable use in harsh industrial environments.
